FLOYD'S TRIANGLE IN C and PYTHON WITH ALGORITHM AND FLOWCHART

What is Floyd's Triangle?

 Floyd's Triangle is the right angled triangular array of natural numbers which starts from 1 at top and have n number of rows.  The sum of numbers in all n rows is given by n(n² + 1)/2.  Numbers on the left edge of the triangle are called Lazy Caterer's Sequence  and the numbers along hypotenuse of triangle are called Triangular numbers. Sequence number of each row is equal to the number of elements in that row. i.e. First row has one number, second row has two and so on.

In this tutorial, you will learn about the algorithm to print Floyd's Triangle of n rows along with flowchart. The coding part is done in both C and Python.



ALGORITHM FOR FLOYD's TRIANGLE

Step 1: Start

Step 2: Read the number of rows of floyd's Triangle.(say n)

Step 3: Iterate the outer loop i upto n times to display rows.

Step 4: Iterate the inner loop from j to i.

Step 5: Display the number

Step 6: Display newline after each row.

Step 7: Stop



FLOWCHART FOR FLOYD's TRIANGLE



SOURCE CODE TO DISPLAY FLOYD's TRIANGLE OF N ROWS

1) In C

//C Program to display Floyd's Triangle of n Rows

#include<stdio.h>
int main(){
   int n,a,b,i,j;
   printf("Enter number of rows");
   scanf("%d",&n);
   a=1;
   for(i=0;i<=n;i++){
      for (j=0;j<=i;j++){
         printf(" %d ",a);
         a++;
      }
      printf("\n");
   }
return 0;
}

2) In python

# Python Program to Display floyd's Triangle of n Rows

n=int(input("Enter number of rows"))

a=1
for i in range(n):
    for j in range(i+1):
        print(a,"",end="")
        a+=1

    print("\n")



Sample Output

Output for both code given above is same.

Enter number of rows 5
1
2 3
4 5 6
7 8 9 10
11 12 13 14 15
